Total Station Leica TC-407 7

Leica TC407 7" Total Station The perfect solution for every construction site. Measuring with the TC407 total station could not be easier! With a laser plummet and electronic level the instrument is quickly set up and ready to measure. The proven endless fine drive and the accurate Leica telescope with 30-times magnification precisely targets each measuring point. The integrated electronic distance meter measures to target plates, prisms or even reflectorless to any given surface. These features save time and money. Angle measurements (Hz, V) # Method Absolute continuous # Display resolution 1" / 0.1 mgon / 0.01 mil # Standard deviation 7" (2 mgon) Telescope # Magnification 30 x # Field of view 1° 30' (26 m at 1 km) # Min. target distance 1.7 m # Reticle illuminated Compensator # System: Electronic 2 axis oil compensator # Setting accuracy 2" Infrared Distance measurement (IR) # Measuring range with circular prism GPR1 3'500 m # Measuring with reflective foil (60 mm x 60 mm) 250 m # Standard deviation (ISO 17123-4) (fine/quick/tracking) 2 mm + 2 ppm/5 mm + 2 ppm/5 mm + 2 ppm # Time for a measurement (fine/quick/tracking) < 1 sec/< 0.5 sec/< 0.15 sec Communication # Internal data storage 10'000 data blocks # Interface RS232 # Data formats GSI/IDEX/ASCII/dxf/Freely definable formats Operation # Display Graphics 160 x 280 pixels, # Alphanumeric 8 lines x 31 characters Laser plummet # Type: Laser point, brightness adjustable in steps # Accuracy 1.5 mm at 1.5 m instrument height INCLUDES: # TCR407 Total Station, 1 Keyboard, laser plummet, onboard memory, carrying case containing serewdriver, shade adjusting pins, hex key, & rain cover. # TPS400 User Manual, English. # CD-ROM TPS User Documentation. # GDF111-1 BASIC Tribrach # GEB121 3.6Ah 6V Camcorder NiMH battery. # GKL112 BASIC Charger # Warranty: One Year
